NANO PRO™ 0.2μl Micro-Volume UV/VIS Spectrophotometer
The NANO PRO™ Microvolume Spectrophotometer is designed for rapid and precise DNA, RNA, and protein quantification with minimal sample volume requirements. Its unique sample holder ensures accurate detection without light loss, guaranteeing reliable measurement results. The device supports quantitative analysis, wavelength scanning, kinetics, and multi-wavelength measurements, making it ideal for biological and clinical research applications.
- Minimal Sample Volume: Allows DNA and protein testing with just a small drop of sample.
- High Accuracy & Precision: Prevents light loss, ensuring consistent and reliable results.
- Multi-Function Capabilities: Supports quantitative testing, kinetics, and wavelength scanning.
- Fast Detection Process: Drop sample, rotate, and detect within seconds.
- Versatile Applications: Suitable for molecular biology, biochemistry, and clinical diagnostics, including colorimetric blood analysis.
Brand: NANO PRO™
Manufacturer: NANOSSR LLC
NANOSSR offers a variety of Microvolume Spectrophotometers. Please contact us for more information.
Specifications:
| SKU# | BB1746 |
| Minimum Sample Capacity | 0.2μl |
| Ultromicro Optical Distance | 0.5mm |
| Detectable Concentration Range | 2.5~-7500ng/ul(dsDNA) |
| Min Precise Detect Concentration | 1Ong/μl(dsDNA) |
| Max Precise Detect Concentration | 5000ng/μl (dsDNA) |
| DNA reproducibility | |
| Wavelength Range | 190-1100nm |
| Spectral Bandwidth | 4nm |
| Optical System | Grating Double beam |
| Wavelength Accuracy | ±0.5nm |
| Wavelength Repeatability | 0.3nm |
| Max Scanning Speed | 4000nm/min |
| Photometric Accuracy | ±0.5%T or ±0.004A @1A |
| Photometric Range | 0~200%T, -0.3~0.3A 0-9999Conc |
| Stray Light | 0.05%T @ 220, 340nm |
| Stability | ±0.001A/h @ 500nm |
| Baseline Flatness | ±0.002A |
| Light Source | Halogen & Deuterium lamp |
| Output | USB Print and data output, Connect PC |
| Power Supply | AC110/220V |
